Descriptions
Its high standards and quality, highly integrated features, fashion appearance of the image, and a unique color visual appeal, but also gives a noble and elegant, cool heart pleasing feeling, so their match up with a more complementary effect, is supporting the preferred parking, hotels, schools, garden villas, enterprises and other occasions.
Specifications
• Operating voltage 220V + 10% / 50HZ
• Motor power 200W
• Ambient temperature -30 ℃ ~ 80 ℃
• Relative humidity ≤95%
• Barrier rod length customized according to site situation
• Total number of ads (block) by the lever length and fixed plate
• Advertising flap size 80mm × 830mm
• Light-box picture size 450mm × 880mm
• LED lights with power supply 16.7A, 15W
• Lift height rod after the rod length may be
• Lift pole time is generally 5S (special requirements can be customized)
• The beam center height 1050mm
• Remote distance ≤30m
• Input Interface + 12V level signal or pulse signal is greater than 100ms; a driving current of less than 10mA
• The communication interface RS485 electrical standards
• Dimensions 450mm × 360mm × 1180mm
